| Warranty: | 1 Year | Applicable components: | 0805,0603,1206 |
|---|---|---|---|
| Name: | SMT Pick and Place Machine | Application: | SMT Production Line,for SMT machine |
| Condition: | new,100% Original,Brand-new | Mounting speed: | 180000 CPH |
| Type: | Automatic | Usage: | SMT Mounting Machine,LED |
| تسليط الضوء: | High Speed SMT chip mounting machine,High Precision SMT chip mounting machine,Automatic SMT Chip Mounting Machine,High Precision SMT chip mounting machine,Automatic SMT Chip Mounting Machine |
||
High Speed Chip Shooter LED SMT Machine SMD LED chip mounter
What is Pick and Place Machine?
Automatic Positioning Machine is used to realize high speed, high precision and automatic positioning of components. It is the most important and complex equipment in the whole SMT production. The machine position is really an industrial precision robot. Through the function of absorption-transfer-position-position, without damaging components and printed circuit boards, it realizes fast and accurate mounting of SMC/SMD components to the processes Specify the Pad position on the PCB Board.
Process SMT components
(1) Process:
Solder paste printing (screen printing)-Dispensing-Installation-Repair-reflow Soldering-Cleaning-Checking-repair
Some Details About The High-Speed Machine HT-F7S:
(first). Magnetic linear motor and servo motor, more accurate, faster, more stable.
(2). Feeding Missing Components automatically, more intelligent and labor-saving
(3). Feeder power stabilizer (Dual motor, more stable)
(4).34 head, part A and part B can be mounted separately. The capacity reaches 150000~170000CPH.
IPC9850 Power: optimal speed 15000-17000CPH (chips per hour)
Global First Patent Number:
ZL 201120237740.9/ZL 201120334606.0/ZL 201220178869.1/
ZL 20122 0415505.0/ZL 2012 2 0415044.7/ZL 20122 0415356.8/ZL 20122 0412061.0
l Apply to the 0.6m, 0.9m,1.2m(0~1.2m)LED hard light Board and LED Strip (Rope Light) etc.
l Apply to LED Strip flexible and hard tube board, panel etc.
Technical Parameter
| HT-F7S | Specifications |
| Length Width Height | 2700*2450*1530mm |
| PCB Length Width |
MAX:1200*330mm MIN:50*50mm
|
| PCB Thickness | 0.5 ~ 5mm |
| Mount Mode | Group to have and group to bond |
| Not available. of Camera | 5 sets of imported cameras |
| System Vision | Vision link, Mark correction |
| Precise Mounting | ± 0.02mm |
| Installation Height | 15±2Mm |
| Mounting Speed | 150000 ~ 170000CPH |
| Element | LED30140/3528/5050/3030/5630/5730/4014/2835 and resistor etc. |
| Speed Components | 0.2mm |
| Eat Station | 68PCS |
| Not available. of the Nozzles | 34PCS |
| Electrical control | Independently researched and developed by ETON |
| Modular Motion Control Card 1 Set | Independently researched and developed by ETON |
| XY Shaft Drive Way | High-grade magnetic linear motor and servo motor |
| How to eat | Power feeder with dual motors |
Shenzhen ETON Automation Equipment Co. LTD. Set up in2011, as a leading manufacturer of Automatic High Speed Pick and Place machine, focus on "High efficiency Low consumption" in the words, meanwhile ETON is also the largest high-tech Manufacturer Made in China with strong ability of design, R&D, production, sales and service.
♦ Certificate Of Honor:
Eton advanced technology and innovation drive the market revolution rapidly, and obtain a number of intellectual property technologies, including 9 invention patents, 112 actual patents, 12 software copyrights.
♦ Our Office and Factory:
We have about 50000 square meters industrial production park and around 300 people in the company. In the market, about 80% of large LED factories are our customers.
♦ Exhibition:
Our company regularly participates in domestic and foreign exhibitions. Domestic exhibitions include Shenzhen, Guangzhou, etc., and foreign exhibitions include India, Pakistan, Vietnam and so on.
FAQ
Q1: Why choose us?
A: We apply professional, high efficiency, low consumption and specialized in research and development, production, sales and service of SMT high speed SMT automation machine.
Q2: What is your delivery date?
A: The delivery date is about 30 working days after receiving the payment.
Q3: What's the reliability of your brand?
A: Our company stick to sincere business, focus on R&D, manufacture intention, attentive service, customer trust.
Q4: What are the main LED products that our machines do for?
A: There are different machines in our company, and different machines apply to different LED lights and components. The main products we can apply: bulb, tube, strip, lamp, panel. Down light, street light, ceiling light. Wall washer light, electricity, controller, lens and so on.
Q5: Is your software interface in English?
A: English interface and Chinese interface are both available .
Q6: The machine is easy to operate?
A: The machine is easy to operate, usually 3 to 5 days training of operation is enough.
